OMNITRONIC P-500, 2 x 250W/4 Ohm

Pris: kr 3199.00



OMNITRONIC P-500, 2 x 250W/4 Ohm

Art nr:                 3002

OMNITRONIC P-500 amplifier, 2x250W/4Ohms

· Powerful professional amplifier

· 2 x 250 W/4 ohm

· Enormous power with highest brilliance

· 2 gain controls on the frontpanel

· All operation modes controllable via LEDs

· LED intensity adjustable via brightness control on the rear panel

· Signal inputs via XLR female or 1/4" jack socket

· Input sensitivity adjustable via selector on the rear panel

· Speaker connection via lockable Speaker plugs or Banana/screw combination

· With limiter

· Ground Lift switch against humming

· Bridged switch for bridging

· Many protection circuits for optimized equipment protection

· Very rugged housing

· 19" dimensions

· High power/weight-relation

28.09.2009 19:27

Power supply:

115/230 V AC, 50/60 Hz ~

Power-range:

230 V ± 10 % (206 V - 253 V)

Power consumption (max.):

1000 W

Momentary music peak power at 1 KHz:

650 W / 4 Ohms

Maximum power output:

2 x 295 W / 4 Ohms

Nominal power output:

2 x 250 W / 4 Ohms

Power output sine:



Stereo 4 Ohm

2 x 250 W

Stereo 8 Ohm

2 x 130 W

8 Ohms bridged

1 x 500 W

Frequency range:

22 - 31 000 Hz

Damping-factor:

> 150

Distortion factor:

0,01 %

Signal to Noise Ratio:

108 dB

Channel seperation (at 1 KHz):

89 dB

Min. input sensitivity:

0,77 V/26 dB/1,44 V

Input impedance:

12 kOhms (unbalanced), 22 kOhms (balanced)

Output impedance:

> 0,02 Ohms

Slew-rate:

> 30 V/ęsec

Input-connectors:

2 x XLR-female-plug, 2 x 1/4"-jack-plug

Output-connectors:

2 x Speaker (stereo), 1 x Speaker (bridge), 2 x Banana/screw combination

Control elements:

Power switch, input attenuators (one per channel), Mode switch - Stereo/Parallel/Bridged, Ground Lift, Input-Level-Select (0.77 V/26 dB/1.44 V), limiter

LED indicators (per channel):

Power, Protect, Signal, Mode

Protection circuits:

Short-circuit, DC-protection-circuit, Thermal protection-circuit, Softstart

Construction:

Steel chassis, aluminium frontpanel

Dimensions:

445 x 482 x 100 mm

Minimum mounting depth:

450 mm

Weight:

10.25 kg
